KC-5200 delivers aggressive scan performance on all linear barcodes. It provides fast and reliable scanning performance that scans 270 times per second. It’s ergonomic design and available with combo interface that changes interface by replacing cable. KC-5200 is valued product of general purpose cabled scanner. It’s perfect for using in retail, document/billing process and banking/finance environment. KC-5200 is enable presentation scanning configuration which provides object detection and in-stand scanning.
specification
General
Interface
USB-HID / USB-COM / RS-232
Barcode supported
All UPC/EAN/JAN, EAN128 Code, Code 39, Code 39 Full ASCII, Code32 / Italian Pharmacode, Code 128, CODABAR/NW7, Interleave 2 of 5, Industrial 2 of 5, Matrix 2 of 5, MSI/PLESSEY, Telepen, Code 93, Code 11, China Postage, GS1 DataBar
Optical
Optical sensor
2500 pixels
Light Source
Red LED (660mm)
Resolution
4 mil
Depth of Field
10 – 390mm
Scan rate
270 scans/sec
PCS
45%
Indicator
Beeper and LED
Electrical
Voltage
+ 5V ± 5%
Scannig currents
120mA Typical
Standby currents
70 mA
Environment
Operating temperature
0 °C to 40 °C / 32 °F to 104 °F
Storage temperature
-40 °C to 70 °C / -40 °F to 158 °F
Operating humidity
10% ~95% RH non-condensing
Storage humidity
10% ~85% RH non-condensing
Shock resistance
1.5m drops
Physical
Weight
180g
Dimensions
185mm (L) x 67mm (W) x 91mm (H)
Housing Material
ABS plastic
Cable
Length: 5ft (150cm) / USB Type: A or C, RS-232
Warranty
1 year
Certificate
CE / FCC
