Stationary Area Imager
DT-50
- Scan e-barcodes
- Desktop or integrated in Kiosk
- Read 2 barcodes at the same time
- IP 54 sealing
The NUMA DT-50 Desktop 2D Barcode Scanner delivers fast and reliable decoding for all 1D, PDF, and 2D barcodes, including QR codes from smartphone screens and poorly printed paper labels. Designed for modern retail, hospitality, and entertainment environments, it enables effortless mobile coupon redemption, digital ticket scanning, and electronic key access. With its sleek design, plug-and-play setup, and powerful imaging performance, the DT-50 is the ideal choice for businesses embracing mobile commerce and contactless customer interaction.
specification
General
Interface
USB-KB / USB-COM / RS-232
Barcodes Supported (1D)
UPC-A, UPC-E, EAN-13, EAN-8, Code 128, GS1-128, Code-39, Code-32, Code-93, Pharmacode Codabar/NW7, MSI, Interleaved 2 of 5, GS1 DataBar-14, GS1 DataBar Stacked, GS1 DataBar Limited GS1 DataBar Expanded, GS1 DataBar Expanded Stacked, Composite Component A / B / C
Barcodes Supported (2D)
PDF417, Micro PDF417, QR Code, Micro QR Code, Data Matrix, Aztec, Maxi Code, Dot Code
Optical
Optical System
640 (H) x 480 (V) pixels
Light Source
Aiming 610nm red LED + Illumination 6000-6500k white LED
Resolution
5 mil (Code 39)
Scan Rate
120 fps
Focusing Point
15mm
Field of View
Horizontal: 75°; Vertical: 60°
PCS
30%
Indicator
Beeper and LED
Electrical
Voltage
DC 5V
Scanning Current
140 mA
Standby Current
110 mA
Environment
Operating Temperature
0℃ to 40℃ (32℉ to 104℉)
Storage Temperature
-40℃ to 70℃ (-40℉ to 158℉)
Operating Humidity
10% - 95% RH (Non-condensing)
Storage Humidity
10% - 85% RH (Non-condensing)
Shock resistance
1.5m drops
Light Level
100,000 lux
Physical
Weight
103g w/cable
Dimension
51.92mm (L) x 61.35mm (W) x 28.5mm (H)
Housing Material
ABS plastic / Window - Tempered glass
Cable
Length: 5ft (150cm) / USB Type: A, RS-232
Warranty
1 year
Certificate
CE, FCC, BSMI, VCCI
Sealing IP 54
